Forged Steel - Globe Valves - Y-Pattern Welded Bonnet - Class 2500 (OS&Y Rising Stem -Socket Weld Ends)
Figure No. 9599
(Larger sizes available on application)
Ratings (ASTM A105):
- 6,170 psi at -20°F to 100°F
Test Pressure (API 598):
- Hydraulic: Shell - 9,275 psi
- Seat: - 6,790 psi
- Air: Seat - 80 psi
Forged Steel Globe Valves Y-Pattern Welded Bonnet
STANDARD MATERIALS
Forging Material Body and Bonnet
Trim Material
A105
API Trim 8
A182 F11
API Trim 8
A182 F22
API Trim 8
A182 F5
API Trim 8
A182 F9
API Trim 8
A182 F316
API Trim 12
A182 F316L
API Trim 12
A350 LF2
API Trim 8
